Round Baler

SRB 60+ SL

* The Company reserves absolute rights to modify the specifications of machine and components therein without any prior notice.

Enquiry Download

Advantages

  • Continuous Bailing: Enables continuous baling without interruptions, eliminating the need to stop and manually adjust the binding mechanism
  • Consistent Density: Ensures uniform bale density by minimizing compression variations throughout the bale
  • Reduced Labour Input: Automatic binding eliminates the need for manual intervention, significantly reducing labor requirements during the baling operation
  • Fewer Adjustments: Eliminates the need for manual adjustments, minimizing operator error and reducing downtime

Features

  • Scale Less Binding Unit
  • Five Row PickUp
  • Extended Side Plate
  • Aluminum Gearbox
  • Heavy Duty Chains
  • Shear Bolt
  • Heavy Duty Roller
  • Chain Lubrication System
  • Wider Tyres with Adjustable Track
  • Bale Size

Technical Specification

Parameter SRB 60 + SRB 45
Overall Length (mm) 1335 1245 x (1686 – 1826 ) x 1240
Overall Width (mm) Min. 1590 Min. 1686
Max. 1660 Max. 1826
Overall Height (mm) 1230 1240
Working Width (mm) 925 1030
Ground Clearance (axle height) (mm) 180 180
Tractor Power (HP) & PTO speed (RPM) 30 HP- 50 HP (@ 540 ) 27 HP – 50 HP (@ 540 )
Hitching System 3 Point Linkage CAT 11 3 Point Linkage CAT 1 1
No. of Bars 5 5
No. of Tynes 90 90
No. of Rollers 12 10
Bale Size (mm) Diameter – 610, Width – 915 Diameter – 460, Width – 1040
Working Capacity (Bales/hr) 55 – 60 * 60 – 65 *
Bale Weight (kg) 17 – 35 ** 14 – 30 **
Baler Weight (kg) 550 553 Approx.
Binding Twine Jute / Polypropylene Jute / Polypropylene
Binding Activation Scale Less Auto Binding system Scale Less Auto Binding system
Track Width (mm) Adjustabe track ( 1590 – 1660 ) Adjustable track ( 1515 – 1655 )
Tyre Size & Ply Rating 16 x 6.5 – 8 PR 16 x 6.5 – 8 PR
Drive Line Safety Slip Clutch & Shear Bolt Slip Clutch & Shear Bolt
Chamber Type Fixed with Steel Rollers Fixed with Steel Rollers
